Brand Name : PEAKMETER
Model Number : PM838
Certification : CE
Place of Origin : China
MOQ : 1
Price : Negotiation
Payment Terms : T/T
Supply Ability : 150,000 Pcs Per Month
Delivery Time : 5-40 work days
Packaging Details : Product Size 138x69x31mm Product Weight Approx. 170g
Function 1 : Diode test
Measuring Current : 10A DC
Function 2 : Continuity
Measuring Resistance : 0Ω-2MΩ
Product Name : Digital Multimeter
Measuring Voltage : 0~600V AC/DC
| Specifications | Range | Accuracy |
| DC Voltage | 200mV/2V/20V/200V | ±(0.5%+2) |
| 600V | ±(0.8%+2) | |
| AC Voltage | 200V/600V | ±(1.2%+10) |
| DC Current | 200µA/2mA | ±(1.0%+3) |
| 20mA | ±(1.0%+5) | |
| 200mA | ±(1.5%+5) | |
| 10A | ±(3.0%+10) | |
| Resistance | 200Ω/2kΩ/20kΩ/200kΩ | ±(0.8%+2) |
| 2MΩ | ±(1.0%+5) | |
| Features | ||
| Display | 2000 counts | |
| Data Hold | √ | |
| Diode Test | √ | |
| Continuity | √ | |
| Temperature | √ | |
| General | ||
| Power Supply | DC9V 6F22 battery | |
| Net weight | 186g (battery is not included) | |
| Gross weight | 330g | |
| Size | 145mm*74mm*44mm | |
| Safety Rating | EN61010-1, EN61010-2-033, EN61326, CAT. Ⅲ 600V | |
This instrument can measure DC Voltage, AC Voltage, DC Current, Resistance, Capacitance,Continuity, Diode and temperature.


|
|
